Fujitsu 8kW Multi Head Outdoor Unit Only AOTG30LBTA4

FujitsuModel: AOTG30LBTA4

Sale price$2,794.00 Regular price$3,216.00


Fujitsu 8kW Multi Head Outdoor Unit Only AOTG30LBTA4 - Reverse Cycle

Fujitsu Reverse Cycle (R410A) Outdoor Unit Only AOTG30LBTA4

8kW Cooling – 9.6kW Heating capacity

Max Connectable indoor units: 4


 Fujitsu multi brochure


Model No. – Outdoor AOTG30LAT4
Reverse Cycle System Yes
Cooling Capacity (Watts) 8000
Cooling Capacity (BTU/h) 27300
Range (Watts) 3500-10100
Range (BTU/h) 11,940-34,500
Heating Capacity (Watts) 9600
Heating Capacity (BTU/h) 32800
Range (Watts) 3700-12000
Range (BTU/h) 12620-41000
Power Supply (Volts) 240
Phase-Frequency (Ph – Hz) 1-50
Power Supply Attachment Outdoor
Plug Size (If Applicable) NA
Running Current, Cooling (Amps) 9.3
Running Current, Range (Amps) Max 15.0
Running Current, Heating (Amps) 10.01
Running Current, Range (Amps) Max 15.00
Input, Cooling (Watts) 2220
Input, Range (Watts) Max 3560
Input, Heating (Watts) 2400
Input, Range (Watts) Max 3580
E.E.R. – Cooling 3.6
C.O.P. – Heating 4
Fan Speed 2
Compressor Type Twin Rotary
Dimensions -Outside Unit (HxWxD mm) 830x900x330
Weight – Outside unit (Kg) 68
O.U. Sound Pressure Level (dBA @1mtr) 50
O.U. Sound Power Level (dBA) 64
Refrigerant Type R410A
Connection Pipe Sizes, Gas (mm) 2 X 9.52, 2 X 12.7
Connection Pipe Sizes, Liquid (mm) 4 X 6.35
Pre Charged Length (Metre) 50
Minimum Pipe Length (Metre) 20
Maximum Pipe Length per unit (Metre) 25
Maximum Pipe Length (Metre) Max Total 70
Maximum Pipe Height (Metre) 15 (IU TO OU)
Pipe Connection Methods Flare
Outdoor operating Temp, Cooling ℃ 0 to 46
Outdoor operating Temp, Heating ℃ -10 to 24
